Please contact us for more photos of SY-12-K
| Part Number | SY-12-K |
|---|---|
| Manufacturer | Fujitsu |
| Quantity in stock | 353030 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay SPDT 1A 12VDC 960Ohm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | SY-12-K |
| Datasheet download |  SY-12-K.pdf |
| Part Number | SY-12-K |
|---|---|
| Contact Material | Silver Palladium |
| Mounting | Through Hole |
| Coil Resistance | 960 Ohm |
| Minimum Dropout Voltage | 0.6 Vdc |
| Lead Free | Yes |
| Maximum Current Rating | 1 A |
| DC Coil Voltage | 12 |
| Maximum Pick-Up Voltage | 8.4 Vdc |
| Relay Construction | Non-Latching |
| Coil Current | 12.5 mA |
| Operate Time | 5 ms |
| Maximum DC Voltage Rating | 60 V |
| Maximum AC Voltage Rating | 120 V |
| Contact Arrangement | SPDT |
| Family | SY |
| Rad Hard | No |
| Package Dimensions | 7.4 x 12.5 x 9.5 |
| Termination Style | PC Pins |
| Type | Miniature Relay |
| Maximum Power Rating | 24 W |
| RoHS | YES |
| Operating Temperature | -30 to 90 °C |
| Product Depth | 7.4 mm |
| Product Height | 9.5 mm |
| Product Length | 12.5 mm |
| Replacement Part Number | PART-SY-12-K |
| Weight | Contact us |
| Country of Origin | - |
