Please contact us for more photos of TQ2-9V
| Part Number | TQ2-9V |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 276200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay DPDT 1A 9VDC 579Ohm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | TQ2-9V |
| Datasheet download |  TQ2-9V.pdf |
| Part Number | TQ2-9V |
|---|---|
| Operate Time | 3 ms |
| Rad Hard | No |
| Minimum Dropout Voltage | 0.9 Vdc |
| Product Dimensions | 14 x 9 x 5 mm |
| Contact Arrangement | DPDT |
| Supplier Package | DIP |
| Contact Material | Silver/Gold Clad |
| Operating Temperature | -40 to 70 °C |
| Relay Construction | Non-Latching |
| Coil Resistance | 579 Ohm |
| Mounting | Through Hole |
| Product Depth | 9 mm |
| Product Height | 5 mm |
| Product Length | 14 mm |
| Replacement Part Number | PART-TQ2-9V |
| Weight | Contact us |
| Country of Origin | - |
