ESD204B102ELSE6327XTSA1 Infineon

ESD204B102ELSE6327XTSA1 Images

Please contact us for more photos of ESD204B102ELSE6327XTSA1

Part Number	ESD204B102ELSE6327XTSA1
Manufacturer	Infineon
Quantity in stock	133770 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	ESD Suppressor TVS \u00b120KV 2-Pin TSSLP T R
Category	Discrete Semiconductor
Family	Diode
ROHS Compliant	Yes
MSL Level	ESD204B102ELSE6327XTSA1
Datasheet download	ESD204B102ELSE6327XTSA1.pdf

Request Quotation for ESD204B102ELSE6327XTSA1

ESD204B102ELSE6327XTSA1 Specifications

Part Number	ESD204B102ELSE6327XTSA1
Direction Type	Bi-Directional
Maximum Clamping Voltage	28 V
Product Dimensions	0.62 x 0.32 x 0.26(Max)
Maximum Working Voltage	14 V
ESD Protection Voltage	±20@Air Gap\|±18@Contact Disc kV
Number of Elements per Chip	1
Maximum Leakage Current	0.05 uA
Supplier Package	TSSLP
Capacitance Value	7 pF
Pin Count	2
Rad Hard	No
Configuration	Single
MSL Level	1
Mounting	Surface Mount
Max Processing Temp	260
Lead Finish	Matte Tin
Type	TVS
Package	2TSSLP
Replacement Part Number	PART-ESD204B102ELSE6327XTSA1
Weight	Contact us
Country of Origin	-
