Please contact us for more photos of PESD5V0S1BSF,315
| Part Number | PESD5V0S1BSF,315 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 802350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ESD Suppressor TVS 40KV 2-Pin DSN |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | PESD5V0S1BSF,315 |
| Datasheet download |  PESD5V0S1BSF,315.pdf |
| Part Number | PESD5V0S1BSF,315 |
|---|---|
| Number of Elements per Chip | 1 |
| Product Dimensions | 0.63 x 0.33 x 0.31 mm |
| ESD Protection Voltage | 40@Air Gap/30@Contact Disc/30@HBM kV |
| Max Processing Temp | 260 |
| Pin Count | 2 |
| Maximum Leakage Current | 0.1 uA |
| Type | TVS |
| Maximum Clamping Voltage | 15.5 V |
| Rad Hard | No |
| Direction Type | Bi-Directional |
| Supplier Package | DSN |
| Lead Finish | Tin |
| Capacitance Value | 45 pF |
| Maximum Working Voltage | 5 V |
| Mounting | Surface Mount |
| Replacement Part Number | PART-PESD5V0S1BSF,315 |
| Weight | Contact us |
| Country of Origin | - |
