12-215 Y2C-BR1S1L 3C Everlight

Please contact us for more photos of 12-215 Y2C-BR1S1L 3C

Part Number	12-215 Y2C-BR1S1L 3C
Manufacturer	Everlight
Quantity in stock	469260 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Yellow 591nm 2-Pin Chip LED T R
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	12-215 Y2C-BR1S1L 3C
Datasheet download	12-215 Y2C-BR1S1L 3C.pdf

Request Quotation for 12-215 Y2C-BR1S1L 3C

12-215 Y2C-BR1S1L 3C Specifications

Part Number	12-215 Y2C-BR1S1L 3C
Rad Hard	No
Lens Shape Type	Rectangular
Mounting	Surface Mount
Supplier Package	Chip LED
Reverse Voltage	5 V
Category	Chip LED
Mounting Orientation	Right Angle
Viewing Angle	130 °
Lens Dimensions	1.7x0.6x0.5 mm
Lens Appearance	Colorless Non Diffused
Color	Yellow
Number of LEDs	1
Maximum Forward Voltage per Color	2.3 V
Peak Wavelength	591 nm
Intensity	225(Max) mcd
Dominant Wavelength	594.5(Max) nm
Operating Temperature	-40 to 85 °C
Product Dimensions	2.1 x 0.6 x 1 mm
LED Material	AlGaInP
Maximum Forward Current	25 mA
Maximum Power Dissipation	60 mW
Pin Count	2
Type	Uni-Color
Package	2Chip LED
Replacement Part Number	PART-12-215 Y2C-BR1S1L 3C
Weight	Contact us
Country of Origin	-
