Please contact us for more photos of FAN2310MPX
| Part Number | FAN2310MPX |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 713520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 15V 34-Pin PQFN T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | FAN2310MPX |
| Datasheet download |  FAN2310MPX.pdf |
| Part Number | FAN2310MPX |
|---|---|
| Type | Step Down |
| Minimum Input Voltage | 4.5 V |
| Pin Count | 34 |
| Efficiency | 96 % |
| Number of Outputs | 1 |
| Switching Frequency | 200 to 1500 kHz |
| Minimum Isolation Voltage | |
| Output Type | Adjustable |
| Supplier Package | PQFN |
| Switching Regulator | Yes |
| Screening Level | Industrial |
| Lead Finish | Gold Over Nickel Palladium |
| Rad Hard | No |
| Maximum Input Voltage | 15 V |
| Mounting | Surface Mount |
| Operating Supply Voltage | 4.5 to 15 V |
| Maximum Output Current | 10 A |
| Output Voltage | 0.6 to 5.5 V |
| Operating Temperature | -40 to 85 °C |
| MSL Level | 1 |
| Product Dimensions | 5.5 x 5 x 1.05 |
| Max Processing Temp | 260 |
| Package | 34PQFN |
| Replacement Part Number | PART-FAN2310MPX |
| Weight | Contact us |
| Country of Origin | - |
