FDMF5820DC Fairchild Semiconductor

FDMF5820DC Images

Please contact us for more photos of FDMF5820DC

Part Number	FDMF5820DC
Manufacturer	Fairchild Semiconductor
Quantity in stock	889040 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Smart Power Stage Module 31-Pin PQFN T R
Category	Power Supplies
Family	Power Misc
ROHS Compliant	Yes
MSL Level	FDMF5820DC
Datasheet download	FDMF5820DC.pdf

Request Quotation for FDMF5820DC

FDMF5820DC Specifications

Part Number	FDMF5820DC
Rad Hard	No
Mounting	Surface Mount
Operating Temperature	-40 to 125 °C
MSL Level	1
Screening Level	Extended Industrial
Max Processing Temp	260
Category	Smart Power Stage Module
Product Dimensions	5 x 5 x 0.75(Max)
Pin Count	31
Lead Finish	Matte Tin
Type	Smart Power Stage Module
Supplier Package	PQFN
Package	31PQFN
Replacement Part Number	PART-FDMF5820DC
Weight	Contact us
Country of Origin	-
