Please contact us for more photos of 74HCT112D,653
| Part Number | 74HCT112D,653 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 375720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Flip Flop JK-Type Neg-Edge 2-Element 16-Pin SO T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74HCT112D,653 |
| Datasheet download |  74HCT112D,653.pdf |
| Part Number | 74HCT112D,653 |
|---|---|
| Maximum High Level Output Current | -6 mA |
| Number of Channels per Chip | 2 |
| Typical Operating Supply Voltage | 5 V |
| Output Signal Type | Differential |
| Fabrication Technology | CMOS |
| Propagation Delay Test Condition | 50 pF |
| Maximum Low Level Output Current | 6 mA |
| Number of Element Inputs | 2 |
| Minimum Operating Supply Voltage | 4.5 V |
| Logic Function | JK-Type |
| Max Processing Temp | 250|260 |
| Set/Reset | Set/Reset |
| Polarity | Inverting/Non-Inverting |
| Logic Family | HCT |
| Pin Count | 16 |
| Maximum Quiescent Current | 0.004 mA |
| Lead Finish | Gold |
| Rad Hard | No |
| Mounting | Surface Mount |
| Number of Element Outputs | 1 |
| MSL Level | 1 |
| Product Dimensions | 10 x 4 x 1.45 mm |
| Triggering Type | Negative-Edge |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum Propagation Delay Time @ Maximum CL | [email protected] ns |
| Input Signal Type | Single-Ended |
| Operating Temperature | -40 to 125 °C |
| Supplier Package | SO |
| Number of Output Enables per Element | 0 |
| Number of Elements per Chip | 2 |
| Bus Hold | No |
| Package | 16SO |
| Replacement Part Number | PART-74HCT112D,653 |
| Weight | Contact us |
| Country of Origin | - |
