| Part Number | BCP56-16T1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 762200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 80V 1A 4-Pin(3+Tab) SOT-223 T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | BCP56-16T1G |
| Datasheet download |  BCP56-16T1G.pdf |
| Part Number | BCP56-16T1G |
|---|---|
| Product Dimensions | 6.5 x 3.5 x 1.57 mm |
| Max Processing Temp | 260 |
| Minimum DC Current Gain | 25@5mA@2V|100@150mA@2V|25@500mA@2V |
| Type | NPN |
| Pin Count | 4 |
| Operating Temperature | -65 to 150 °C |
| Maximum Collector Emitter Voltage | 80 V |
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Maximum DC Collector Current | 1 A |
| Maximum Collector Base Voltage | 100 V |
| Maximum Collector Emitter Saturation Voltage | 0.5@50mA@500mA V |
| Supplier Package | SOT-223 |
| Maximum Power Dissipation | 1500 mW |
| Maximum Emitter Base Voltage | 5 V |
| Mounting | Surface Mount |
| Rad Hard | No |
| Package | 4SOT-223 |
| Replacement Part Number | PART-BCP56-16T1G |
| Weight | Contact us |
| Country of Origin | - |
