Please contact us for more photos of FMBA06
| Part Number | FMBA06 |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 766510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 80V 0.5A 6-Pin SuperSOT T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | FMBA06 |
| Datasheet download |  FMBA06.pdf |
| Part Number | FMBA06 |
|---|---|
| Minimum DC Current Gain | 100@10mA@1V|100@100mA@1V |
| Type | NPN |
| Operating Temperature | -55 to 150 °C |
| Max Processing Temp | 260 |
| Maximum Collector Emitter Voltage | 80 V |
| Product Dimensions | 3 x 1.7 x 1 mm |
| Rad Hard | No |
| Maximum Emitter Base Voltage | 4 V |
| Lead Finish | Matte Tin |
| Maximum Collector Emitter Saturation Voltage | 0.25@10mA@100mA V |
| Mounting | Surface Mount |
| Pin Count | 6 |
| Maximum Collector Base Voltage | 80 V |
| Supplier Package | SuperSOT |
| Maximum Power Dissipation | 700 mW |
| MSL Level | 1 |
| Maximum DC Collector Current | 0.5 A |
| Package | 6SuperSOT |
| Replacement Part Number | PART-FMBA06 |
| Weight | Contact us |
| Country of Origin | - |
