Please contact us for more photos of FMBM5551
| Part Number | FMBM5551 |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 630560 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 160V 0.6A 6-Pin SuperSOT T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | FMBM5551 |
| Datasheet download |  FMBM5551.pdf |
| Part Number | FMBM5551 |
|---|---|
| Maximum Emitter Base Voltage | 6 V |
| Product Dimensions | 3 x 1.7 x 1 mm |
| Operating Temperature | -55 to 150 °C |
| Max Processing Temp | 260 |
| Type | NPN |
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Maximum Collector Base Voltage | 180 V |
| Mounting | Surface Mount |
| Maximum Base Emitter Saturation Voltage | 1@1mA@10mA|1@5mA@50mA V |
| Maximum DC Collector Current | 0.6 A |
| Maximum Collector Emitter Saturation Voltage | 0.15@1mA@10mA|0.2@5mA@50mA V |
| Supplier Package | SuperSOT |
| Maximum Power Dissipation | 700 mW |
| Minimum DC Current Gain | 80@1mA@5V|80@10mA@5V|30@50mA@5V |
| Maximum Collector Emitter Voltage | 160 V |
| MSL Level | 1 |
| Pin Count | 6 |
| Package | 6SuperSOT |
| Replacement Part Number | PART-FMBM5551 |
| Weight | Contact us |
| Country of Origin | - |
