Please contact us for more photos of NSS35200MR6T1G
| Part Number | NSS35200MR6T1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 364660 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT PNP 35V 2A 6-Pin TSOP T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | NSS35200MR6T1G |
| Datasheet download |  NSS35200MR6T1G.pdf |
| Part Number | NSS35200MR6T1G |
|---|---|
| Minimum DC Current Gain | 100@1mA@2V|100@500mA@2V|100@2A@3V |
| Operating Temperature | -55 to 150 °C |
| Supplier Package | TSOP |
| Max Processing Temp | 260 |
| Type | PNP |
| Rad Hard | No |
| Maximum Emitter Base Voltage | 5 V |
| Maximum Collector Emitter Voltage | 35 V |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Pin Count | 6 |
| Maximum Power Dissipation | 1000 mW |
| Maximum DC Collector Current | 2 A |
| Maximum Collector Emitter Saturation Voltage | [email protected]@0.8A|[email protected]@1.2A|[email protected]@2A V |
| Maximum Collector Base Voltage | 55 V |
| MSL Level | 1 |
| Maximum Base Emitter Saturation Voltage | [email protected]@1.2A V |
| Product Dimensions | 3 x 1.5 x 0.94 mm |
| Package | 6TSOP |
| Replacement Part Number | PART-NSS35200MR6T1G |
| Weight | Contact us |
| Country of Origin | - |
