Please contact us for more photos of NSS60600MZ4T1G
| Part Number | NSS60600MZ4T1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 105160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT PNP 60V 6A 4-Pin(3+Tab) SOT-223 T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | NSS60600MZ4T1G |
| Datasheet download |  NSS60600MZ4T1G.pdf |
| Part Number | NSS60600MZ4T1G |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 6.5 x 3.5 x 1.57 mm |
| Pin Count | 4 |
| MSL Level | 1 |
| Maximum Power Dissipation | 2000 mW |
| Mounting | Surface Mount |
| Supplier Package | SOT-223 |
| Maximum Collector Emitter Voltage | 60 V |
| Minimum DC Current Gain | 150@500mA@2V|120@1A@2V|100@2A@2V|70@6A@2V |
| Maximum Collector Emitter Saturation Voltage | 0.05@[email protected]|[email protected]@1A|[email protected]@2A|0.25@60mA@3A|[email protected]@6A V |
| Maximum Base Emitter Saturation Voltage | [email protected]@1A V |
| Operating Temperature | -55 to 150 °C |
| Maximum Collector Base Voltage | 100 V |
| Max Processing Temp | 260 |
| Type | PNP |
| Maximum DC Collector Current | 6 A |
| Rad Hard | No |
| Maximum Emitter Base Voltage | 6 V |
| Package | 4SOT-223 |
| Replacement Part Number | PART-NSS60600MZ4T1G |
| Weight | Contact us |
| Country of Origin | - |
