Part Number PMBT3904M,315
Manufacturer Nexperia
Quantity in stock 319930 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans GP BJT NPN 40V 0.2A 3-Pin DFN T R
Category Discrete Semiconductor
Family Bipolar Transistor
ROHS Compliant Yes
MSL Level PMBT3904M,315
Datasheet download PMBT3904M,315.pdf
Request Quotation for PMBT3904M,315

PMBT3904M,315 Specifications

Part Number PMBT3904M,315
Type NPN
Maximum Power Dissipation 590 mW
Maximum Collector Base Voltage 60 V
Max Processing Temp 260
Maximum DC Collector Current 0.2 A
Maximum Emitter Base Voltage 6 V
Maximum Collector Emitter Voltage 40 V
Rad Hard No
Pin Count 3
Supplier Package DFN
Mounting Surface Mount
MSL Level 1
Product Dimensions 1.02 x 0.62 x 0.47 mm
Operating Temperature -55 to 150 °C
Maximum Collector Emitter Saturation Voltage 0.2@1mA@10mA|0.3@5mA@50mA V
Minimum DC Current Gain [email protected]@1V|80@1mA@1V|100@10mA@1V|60@50mA@1V|30@100mA@1V
Maximum Base Emitter Saturation Voltage 0.85@1mA@10mA|0.95@5mA@50mA V
Lead Finish Tin
Package 3DFN
Replacement Part Number PART-PMBT3904M,315
Weight Contact us
Country of Origin -
