| Part Number | ZTX690BSTZ |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 530530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 45V 2A 3-Pin E-Line Box |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | ZTX690BSTZ |
| Datasheet download |  ZTX690BSTZ.pdf |
| Part Number | ZTX690BSTZ |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 4.77 x 2.41 x 4.01 mm |
| Minimum DC Current Gain | 500@100mA@2V|400@1A@2V|150@2A@2V |
| Maximum Base Emitter Saturation Voltage | 0.9@10mA@1A V |
| Maximum Collector Emitter Saturation Voltage | [email protected]@0.1A|0.5@5mA@1A V |
| Mounting | Through Hole |
| Maximum Power Dissipation | 1000 mW |
| MSL Level | 1 |
| Pin Count | 3 |
| Maximum Collector Base Voltage | 45 V |
| Maximum DC Collector Current | 2 A |
| Supplier Package | E-Line |
| Operating Temperature | -55 to 200 °C |
| Rad Hard | No |
| Type | NPN |
| Max Processing Temp | 260 |
| Maximum Emitter Base Voltage | 5 V |
| Maximum Collector Emitter Voltage | 45 V |
| Package | 3E-Line |
| Replacement Part Number | PART-ZTX690BSTZ |
| Weight | Contact us |
| Country of Origin | - |
