ZTX790ASTZ Diodes Incorporated

Please contact us for more photos of ZTX790ASTZ

Part Number	ZTX790ASTZ
Manufacturer	Diodes Incorporated
Quantity in stock	539780 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans GP BJT PNP 40V 2A 3-Pin E-Line Box
Category	Discrete Semiconductor
Family	Bipolar Transistor
ROHS Compliant	Yes
MSL Level	ZTX790ASTZ
Datasheet download	ZTX790ASTZ.pdf

Request Quotation for ZTX790ASTZ

ZTX790ASTZ Specifications

Part Number	ZTX790ASTZ
Minimum DC Current Gain	300@10mA@2V\|250@500mA@2V\|200@1A@2V\|150@2A@2V
Maximum Base Emitter Saturation Voltage	1@10mA@1A V
Supplier Package	E-Line
Rad Hard	No
Maximum Emitter Base Voltage	5 V
Type	PNP
Max Processing Temp	260
Operating Temperature	-55 to 200 °C
Lead Finish	Matte Tin
Maximum Collector Emitter Voltage	40 V
Product Dimensions	4.77 x 2.41 x 4.01 mm
Maximum Collector Base Voltage	50 V
Maximum Power Dissipation	1000 mW
Maximum Collector Emitter Saturation Voltage	0.25@5mA@500mA\|0.45@10mA@1A\|0.75@50mA@2A V
MSL Level	1
Pin Count	3
Mounting	Through Hole
Maximum DC Collector Current	2 A
Package	3E-Line
Replacement Part Number	PART-ZTX790ASTZ
Weight	Contact us
Country of Origin	-
