Please contact us for more photos of DRV5053CAQDBZR
| Part Number | DRV5053CAQDBZR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 306920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Hall Effect Sensor 2.3mA Bipolar 2.5V to 38V 3-Pin SOT-23 T R |
| Category | Sensors & Transducers |
| Family | Magnetic Sensors |
| ROHS Compliant | Yes |
| MSL Level | DRV5053CAQDBZR |
| Datasheet download |  DRV5053CAQDBZR.pdf |
| Part Number | DRV5053CAQDBZR |
|---|---|
| Output Current | 2.3 mA |
| Product Dimensions | 2.92 x 1.4(Max) x 1.02(Max) |
| Lead Finish | Gold Over Nickel Palladium |
| Module/IC Classification | IC |
| Operating Supply Voltage | 2.5 to 38 V |
| Maximum Supply Current | 2.7(Typ) mA |
| Supplier Package | SOT-23 |
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Magnetic Type | Bipolar |
| Screening Level | Extended Industrial |
| Operating Temperature | -40 to 125 °C |
| Pin Count | 3 |
| Max Processing Temp | 260 |
| Package | 3SOT-23 |
| Replacement Part Number | PART-DRV5053CAQDBZR |
| Weight | Contact us |
| Country of Origin | - |
