Please contact us for more photos of M80-4C11205F1-04-325-00-000
| Part Number | M80-4C11205F1-04-325-00-000 |
|---|---|
| Manufacturer | Harwin |
| Quantity in stock | 499330 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Datamate 2-Row Mix-Tek Female Crimp Connector, Hexagonal slotted jackscrews, 12 x Small bore signal contacts, 4 x 12 AWG Power contacts |
| Category | Connectors |
| Family | Connector Contacts |
| ROHS Compliant | Yes |
| MSL Level | M80-4C11205F1-04-325-00-000 |
| Datasheet download |  M80-4C11205F1-04-325-00-000.pdf |
| Part Number | M80-4C11205F1-04-325-00-000 |
|---|---|
| Contact Plating | Gold |
| Rad Hard | No |
| Number of Rows | 2 |
| Maximum Voltage Rating | 800|800 Vdc|Vac |
| Body Orientation | Straight |
| Lead Finish | Gold |
| Operating Temperature | -55 to +125 °C |
| Termination Method | Crimp |
| Maximum Contact Resistance | 25 MOhm |
| Housing Color | Black |
| Housing Material | PPS |
| Package Dimensions | 38 x 5.55 x 12.7 mm |
| Type | 2.00 Pitch Datamate Mix-Tek mm |
| Maximum Current Rating | 3 A |
| Gender | F |
| Contact Material | Beryllium Copper contact clip + Brass shell (signal), Brass (power) |
| Number of Contacts | 12 |
| Wire Size | |
| Mounting | Cable (Solder + Crimp) |
| Pitch | 4 mm |
| Color | Black |
| Product Depth | 5.55 mm |
| Product Height | 12.7 mm |
| Product Length | 38 mm |
| Replacement Part Number | PART-M80-4C11205F1-04-325-00-000 |
| Weight | Contact us |
| Country of Origin | - |
