BSM200GB60DLC Infineon

BSM200GB60DLC Images

Please contact us for more photos of BSM200GB60DLC

Part Number	BSM200GB60DLC
Manufacturer	Infineon
Quantity in stock	801120 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans IGBT Module N-CH 600V 200A nom 730W 7-pin 94x34mm
Category	Discrete Semiconductor
Family	IGBT Module
ROHS Compliant	Yes
MSL Level	BSM200GB60DLC
Datasheet download	BSM200GB60DLC.pdf

Request Quotation for BSM200GB60DLC

BSM200GB60DLC Specifications

Part Number	BSM200GB60DLC
Lead Finish	Tin Over Nickel
Maximum Gate Emitter Voltage	±20 V
Channel Type	N
Mounting	Screw
Supplier Package	34MM-1
Maximum Collector Emitter Voltage	600 V
Configuration	Dual
Maximum Continuous Collector Current	230 A
Rad Hard	No
Product Dimensions	94 x 34 x 30.5
Pin Count	7
Package	734MM-1
Replacement Part Number	PART-BSM200GB60DLC
Weight	Contact us
Country of Origin	-
