Please contact us for more photos of BTS4880R
| Part Number | BTS4880R |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 770200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Power Switch Hi Side 0.7A 36-Pin DSO T R |
| Category | Power Management IC |
| Family | Power Switch |
| ROHS Compliant | Yes |
| MSL Level | BTS4880R |
| Datasheet download |  BTS4880R.pdf |
| Part Number | BTS4880R |
|---|---|
| Supply Current | 5 mA |
| Minimum Output Current | 0.7 A |
| Input Voltage | -10 to 45 V |
| Pin Count | 36 |
| Switch On Resistance | 0.15 Ohm |
| Product Dimensions | 15.9 x 11 x 3.25 |
| Rad Hard | No |
| Supplier Package | DSO |
| Type | High Side |
| Max Processing Temp | 260 |
| Number of Outputs | 8 |
| MSL Level | 3 |
| Lead Finish | Matte Tin |
| Operating Supply Voltage Range | 11 to 45 V |
| Maximum Power Dissipation | 3300 mW |
| Mounting | Surface Mount |
| Package | 36DSO |
| Replacement Part Number | PART-BTS4880R |
| Weight | Contact us |
| Country of Origin | - |
