Please contact us for more photos of TLE 4286 G
| Part Number | TLE 4286 G |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 200750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LDO Regulator Pos 5V 0.07A 5-Pin(3+2Tab) SCT-595 |
| Category | Power Management IC |
| Family | Low Dropout Controller |
| ROHS Compliant | Yes |
| MSL Level | TLE 4286 G |
| Datasheet download |  TLE 4286 G.pdf |
| Part Number | TLE 4286 G |
|---|---|
| Load Regulation | 10 mV |
| Maximum Quiescent Current | 0.1 mA |
| Input Voltage Range | 42 to 6 V |
| Accuracy | ±4 % |
| Maximum Input Voltage | 42 V |
| Junction to Ambient | 179 K/W |
| Minimum Input Voltage | 6 V |
| Function | LDO |
| Pin Count | 5 |
| Product Dimensions | 2.9 x 1.6 x 1 mm |
| Max Processing Temp | 260 |
| Output Voltage | 5 V |
| Typical Dropout Voltage @ Current | 0.8@10mA V |
| Supplier Package | SCT-595 |
| Maximum Dropout Voltage @ Current | 1.1@10mA V |
| Polarity | Positive |
| Typical Quiescent Current | 0.06 mA |
| Operating Temperature | -40 to 150 °C |
| Maximum Output Current | 0.07 A |
| Number of Outputs | 1 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Output Type | Fixed |
| Line Regulation | 10 mV |
| Lead Finish | Matte Tin |
| Package | 5SCT-595 |
| Replacement Part Number | PART-TLE 4286 G |
| Weight | Contact us |
| Country of Origin | - |
