Please contact us for more photos of QS3VH253PAG8
| Part Number | QS3VH253PAG8 |
|---|---|
| Manufacturer | Integrated Device Technology |
| Quantity in stock | 419940 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | 2.5V 3.3V Dual 4:1 Mux Demux High Bandwidth Bus Switch |
| Category | Logic & Timing IC |
| Family | Bus Switch |
| ROHS Compliant | Yes |
| MSL Level | QS3VH253PAG8 |
| Datasheet download |  QS3VH253PAG8.pdf |
| Part Number | QS3VH253PAG8 |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| Configuration | 2 x 4:1 |
| Pin Count | 16 |
| Propagation Delay Test Condition | 50 pF |
| Max Processing Temp | 260 |
| Logic Function | Multiplexer/Demultiplexer Bus Switch |
| Supplier Package | TSSOP |
| Moisture Sensitivity Level | 1 |
| Operating Temperature | -40 to 85 °C |
| MSL Level | 1 |
| Maximum On Resistance | 7 |
| Number of Elements per Chip | 1 |
| Typical Operating Supply Voltage | 2.5|3.3 |
| Pitch | 0.65 |
| Number of Inputs per Chip | 8 |
| Product Dimensions | 5 x 4.4 x 1 mm |
| Number of Outputs per Chip | 2 |
| Typical Quiescent Current | 1000 |
| Minimum Operating Supply Voltage | 2.3 |
| Screening Level | Industrial |
| Maximum Quiescent Current | 4000 |
| Maximum Low Level Output Current | 120 |
| Maximum Propagation Delay Time @ Maximum CL | [email protected] ns |
| Lead Finish | Matte Tin |
| Maximum Operating Supply Voltage | 3.6 |
| Package | 16TSSOP |
| Replacement Part Number | PART-QS3VH253PAG8 |
| Weight | Contact us |
| Country of Origin | - |
