ISL21009CFB825Z Intersil

ISL21009CFB825Z Images

Please contact us for more photos of ISL21009CFB825Z

Part Number ISL21009CFB825Z
Manufacturer Intersil
Quantity in stock 491200 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description V-Ref Precision 2.5V 7mA 8-Pin SOIC N
Category Power Management IC
Family Voltage Reference
ROHS Compliant Yes
MSL Level ISL21009CFB825Z
Datasheet download ISL21009CFB825Z.pdf
Request Quotation for ISL21009CFB825Z

ISL21009CFB825Z Specifications

Part Number ISL21009CFB825Z
Reference Type Precision
Line Regulation 150 uV/V
Product Dimensions 5 x 4 x 1.5 mm
Supplier Package SOIC N
Operating Temperature -40 to 125 °C
Maximum Input Voltage 18 V
Max Processing Temp 260
Rad Hard No
Lead Finish Matte Tin
Mounting Surface Mount
Output Voltage 2.5 V
Topology Series
Maximum Output Current 7 mA
Initial Accuracy 1 mV
MSL Level 1
Load Regulation 100 uV/mA
Maximum Temperature Coefficient 5 ppm/°C
Screening Level Industrial
Pin Count 8
Package 8SOIC N
Replacement Part Number PART-ISL21009CFB825Z
Weight Contact us
Country of Origin -
