Please contact us for more photos of ISL28230CBZ-T7
| Part Number | ISL28230CBZ-T7 |
|---|---|
| Manufacturer | Intersil |
| Quantity in stock | 637270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP R-R I O \u00b12.75V 5.5V 8-Pin SOIC N T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | ISL28230CBZ-T7 |
| Datasheet download |  ISL28230CBZ-T7.pdf |
| Part Number | ISL28230CBZ-T7 |
|---|---|
| Technology | CMOS |
| Typical Voltage Gain | 150 dB |
| Maximum Input Offset Voltage | [email protected] mV |
| Supplier Package | SOIC N |
| Product Dimensions | 4.9 x 3.9 x 1.5 mm |
| Rad Hard | No |
| Minimum Dual Supply Voltage | ±0.9 V |
| Maximum Single Supply Voltage | 5.5 V |
| Maximum Supply Current | 0.05@5V mA |
| Max Processing Temp | 260 |
| Operating Temperature | 0 to 70 °C |
| MSL Level | 2 |
| Typical Single Supply Voltage | 3|5 V |
| Lead Finish | Matte Tin |
| Number of Channels per Chip | 2 |
| Typical Slew Rate | 0.2@5V V/us |
| Minimum CMRR | 110 dB |
| Mounting | Surface Mount |
| Typical Gain Bandwidth Product | 0.4 MHz |
| Typical NonInverting Input Noise Current Density | 0.08@5V pA/rtHz |
| Minimum PSRR | 105 dB |
| Screening Level | Commercial |
| Rail to Rail | Rail to Rail Input/Output |
| Maximum Operating Supply Voltage | ±2.75|5.5 V |
| Power Supply Type | Single|Dual |
| Type | General Purpose Amplifier |
| Maximum Dual Supply Voltage | ±2.75 V |
| Shut Down Support | No |
| Typical Input Noise Voltage Density | 65@5V nV/rtHz |
| Minimum Single Supply Voltage | 1.8 V |
| Pin Count | 8 |
| Maximum Input Bias Current | 0.00025@5V@0C to 70C |
| Package | 8SOIC N |
| Replacement Part Number | PART-ISL28230CBZ-T7 |
| Weight | Contact us |
| Country of Origin | - |
