Please contact us for more photos of MC74HC14ADR2G
| Part Number | MC74HC14ADR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 817110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Inverter Schmitt Trigger 6-Element CMOS 14-Pin SOIC T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | MC74HC14ADR2G |
| Datasheet download |  MC74HC14ADR2G.pdf |
| Part Number | MC74HC14ADR2G |
|---|---|
| Maximum Low Level Output Current | 5.2 mA |
| Mounting | Surface Mount |
| Minimum Operating Supply Voltage | 2 V |
| Supplier Package | SOIC |
| Operating Temperature | -55 to 125 °C |
| Pin Count | 14 |
| Typical Operating Supply Voltage | 2.5|3.3|5 V |
| Product Dimensions | 8.75 x 4 x 1.5 mm |
| Maximum Quiescent Current | 1 uA |
| Logic Family | HC |
| Number of Elements per Chip | 6 |
| Output Type | Schmitt Trigger |
| Input Type | Schmitt Trigger |
| MSL Level | 1 |
| Maximum Propagation Delay Time @ Maximum CL | 75@2V|30@3V|[email protected]|13@6V ns |
| Logic Function | Inverter Schmitt Trigger |
| Maximum High Level Output Current | -5.2 mA |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Maximum Operating Supply Voltage | 6 V |
| Fabrication Technology | CMOS |
| Propagation Delay Test Condition | 50 pF |
| Package | 14SOIC |
| Replacement Part Number | PART-MC74HC14ADR2G |
| Weight | Contact us |
| Country of Origin | - |
