Please contact us for more photos of NC7WV14L6X
| Part Number | NC7WV14L6X |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 763850 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Inverter Schmitt Trigger 2-Element CMOS 6-Pin MicroPak W T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | NC7WV14L6X |
| Datasheet download |  NC7WV14L6X.pdf |
| Part Number | NC7WV14L6X |
|---|---|
| Input Type | Schmitt Trigger |
| Logic Function | Inverter Schmitt Trigger |
| Maximum Operating Supply Voltage | 3.6 V |
| Rad Hard | No |
| Maximum Low Level Output Current | 24 mA |
| Operating Temperature | -40 to 85 °C |
| Minimum Operating Supply Voltage | 0.9 V |
| Output Type | Schmitt Trigger |
| Maximum Quiescent Current | 0.9 uA |
| Product Dimensions | 1.45 x 1 x 0.5 mm |
| Pin Count | 6 |
| Supplier Package | MicroPak W |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Maximum High Level Output Current | -24 mA |
| Logic Family | TinyLogic ULP |
| Number of Elements per Chip | 2 |
| Maximum Propagation Delay Time @ Maximum CL | [email protected] to 1.95V|[email protected] to 2.7V|[email protected] to 3.6V ns |
| Typical Operating Supply Voltage | 1.8|2.5|3.3 V |
| Fabrication Technology | CMOS |
| Propagation Delay Test Condition | 30 pF |
| Package | 6MicroPak W |
| Replacement Part Number | PART-NC7WV14L6X |
| Weight | Contact us |
| Country of Origin | - |
