Please contact us for more photos of C330C105M5U5TATR
| Part Number | C330C105M5U5TATR |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 717500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 1uF 50V Z5U 20% Radial 5.08mm 85\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | C330C105M5U5TATR |
| Datasheet download |  C330C105M5U5TATR.pdf |
| Part Number | C330C105M5U5TATR |
|---|---|
| Operating Temperature | 10 to 85 °C |
| Dielectric | Z5U |
| Voltage(DC) | 50 V |
| Lead Diameter | 0.51 mm |
| Package/Case | 7.62(Max) X 3.81(Max) X 9.14(Max) |
| Lead Pitch For Radial | 5.08 mm |
| Mounting | Through Hole |
| Termination Style | Radial |
| Seated Plane Height | 9.14 mm |
| Case Style | Dipped |
| Rad Hard | No |
| Product Dimensions | 7.62 x 3.81 x 9.14 mm |
| Lead Finish | Matte Tin |
| Tolerance | 20 % |
| Wire Form | Outside Bend |
| Capacitance Value | 1 uF |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Product Depth | 3.81(Max) mm |
| Product Height | 9.14(Max) mm |
| Product Length | 7.62(Max) mm |
| Replacement Part Number | PART-C330C105M5U5TATR |
| Weight | Contact us |
| Country of Origin | - |
