Please contact us for more photos of LDECC3100JA5N00
| Part Number | LDECC3100JA5N00 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 551570 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.1uF 50V PEN 5% 1812 Stacked Wraparound 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | LDECC3100JA5N00 |
| Datasheet download |  LDECC3100JA5N00.pdf |
| Part Number | LDECC3100JA5N00 |
|---|---|
| Voltage(AC) | 40 V |
| Supplier Package | 1812 |
| Voltage(DC) | 50 V |
| Capacitance Value | 0.1 uF |
| Rad Hard | No |
| Max Processing Temp | 255 |
| Case Size | 1812 |
| Pin Count | 2 |
| Tolerance | 5 % |
| Termination Style | Wraparound |
| Dielectric Material | PEN |
| Product Dimensions | 4.7 x 3.3 x 2.4 |
| Construction | Stacked |
| Mounting | Surface Mount |
| Operating Temperature | -55 to 125 °C |
| Package/Case | 1812 |
| Product Depth | 3.3 mm |
| Product Height | 2.4 mm |
| Product Length | 4.7 mm |
| Replacement Part Number | PART-LDECC3100JA5N00 |
| Weight | Contact us |
| Country of Origin | - |
