Please contact us for more photos of T520B227M004ATE035
| Part Number | T520B227M004ATE035 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 497650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 220uF 4V B CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528-21 0.035 Ohm 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | T520B227M004ATE035 |
| Datasheet download |  T520B227M004ATE035.pdf |
| Part Number | T520B227M004ATE035 |
|---|---|
| Construction | Flat |
| Lead Finish | Matte Tin |
| Polarity | Polar |
| Package/Case | 3528-21,B |
| Mounting | Surface Mount |
| Product Dimensions | 3.5 x 2.8 x 1.9 mm |
| Capacitance Value | 220 uF |
| Leakage Current | 88 uA |
| Dissipation Factor | 8 % |
| Equivalent Series Resistance | 0.035 Ohm |
| Voltage(DC) | 4 V |
| MSL Level | 3 |
| Operating Temperature | -55 to 105 °C |
| Case Code | B |
| Case Size | 3528-21 |
| Tolerance | 20 % |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Case Style | Molded |
| Product Depth | 2.8 mm |
| Product Height | 1.9 mm |
| Product Length | 3.5 mm |
| Replacement Part Number | PART-T520B227M004ATE035 |
| Weight | Contact us |
| Country of Origin | - |
