Please contact us for more photos of T520D686M016ATE050
| Part Number | T520D686M016ATE050 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 711050 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 68uF 16V D CASE 20% (7.3 X 4.3 X 2.8mm) SMD 7343-31 0.05 Ohm 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | T520D686M016ATE050 |
| Datasheet download |  T520D686M016ATE050.pdf |
| Part Number | T520D686M016ATE050 |
|---|---|
| Capacitance Value | 68 uF |
| Package/Case | 7343-31,D |
| Construction | Flat |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Polarity | Polar |
| Dissipation Factor | 10 % |
| Case Code | D |
| Voltage(DC) | 16 V |
| Operating Temperature | -55 to 105 °C |
| Case Size | 7343-31 |
| MSL Level | 3 |
| Leakage Current | 108.8 uA |
| Equivalent Series Resistance | 0.05 Ohm |
| Product Dimensions | 7.3 x 4.3 x 2.8 mm |
| Case Style | Molded |
| Rad Hard | No |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Product Depth | 4.3 mm |
| Product Height | 2.8 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-T520D686M016ATE050 |
| Weight | Contact us |
| Country of Origin | - |
