Please contact us for more photos of T521X156M063ATE035
| Part Number | T521X156M063ATE035 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 792610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 15uF 63V X CASE 20% (7.3 X 4.3 X 4mm) SMD 7343-43 0.035 Ohm 125\u00b0C Embossed Plastic T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | T521X156M063ATE035 |
| Datasheet download |  T521X156M063ATE035.pdf |
| Part Number | T521X156M063ATE035 |
|---|---|
| Leakage Current | 94.5@5Min uA |
| Pin Count | 2 |
| Product Dimensions | 7.3 x 4.3 x 4 |
| Case Size | 2917 |
| Case Code | X |
| Voltage(DC) | 63 V |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Package/Case | 7343-43,X |
| Supplier Package | 2917 |
| Dissipation Factor | 10 % |
| Equivalent Series Resistance | 0.035 Ohm |
| Capacitance Value | 15 uF |
| Construction | Flat |
| Lead Finish | Matte Tin |
| Operating Temperature | -55 to 125 °C |
| Case Style | Molded |
| Mounting | Surface Mount |
| Polarity | Polar |
| MSL Level | 3 |
| Rad Hard | No |
| Product Depth | 4.3 mm |
| Product Height | 4 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-T521X156M063ATE035 |
| Weight | Contact us |
| Country of Origin | - |
