Please contact us for more photos of MC74LCX373DTR2G
| Part Number | MC74LCX373DTR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 253140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Latch Transparent 3-ST 8-CH D-Type 20-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | MC74LCX373DTR2G |
| Datasheet download |  MC74LCX373DTR2G.pdf |
| Part Number | MC74LCX373DTR2G |
|---|---|
| Latch Mode | Transparent |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected] ns |
| Maximum Operating Supply Voltage | 3.6 V |
| Bus Hold | No |
| Rad Hard | No |
| Product Dimensions | 6.6 x 4.5 x 1.05 mm |
| Typical Operating Supply Voltage | 2.5|3.3 V |
| Operating Temperature | -40 to 85 °C |
| Maximum Low Level Output Current | 24 mA |
| Number of Output Enables per Element | 1 |
| Minimum Operating Supply Voltage | 2 V |
| Set/Reset | No |
| Maximum Quiescent Current | 10 uA |
| Maximum High Level Output Current | -24 mA |
| Propagation Delay Test Condition | 50 pF |
| Mounting | Surface Mount |
| Polarity | Non-Inverting |
| Max Processing Temp | 260 |
| Logic Family | LCX |
| Number of Outputs per Chip | 8 |
| Number of Channels per Chip | 8 |
| Supplier Package | TSSOP |
| Pin Count | 20 |
| MSL Level | 1 |
| Number of Elements per Chip | 1 |
| Lead Finish | Gold |
| Tolerant I/Os | 5 V |
| Output Type | 3-State |
| Fabrication Technology | CMOS |
| Number of Selection Inputs per Element | 0 |
| Number of Input Enables per Element | 1 |
| Type | D-Type |
| Number of Inputs per Chip | 8 |
| Package | 20TSSOP |
| Replacement Part Number | PART-MC74LCX373DTR2G |
| Weight | Contact us |
| Country of Origin | - |
