Please contact us for more photos of HCPL-5430
| Part Number | HCPL-5430 |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 530560 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler Logic-Out Three State DC-IN 2-CH 8-Pin CDIP |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCPL-5430 |
| Datasheet download |  HCPL-5430.pdf |
| Part Number | HCPL-5430 |
|---|---|
| Minimum Forward Voltage | 1 V |
| Maximum Forward Current | 10 mA |
| Rad Hard | Yes |
| Maximum Reverse Voltage | 3 V |
| Maximum Baud Rate | 40 Mbps |
| Screening Level | Commercial |
| Mounting | Through Hole |
| Input Type | DC |
| Pin Count | 8 |
| Product Dimensions | 9.91 x 7.57 x 4.32 mm |
| Direction Type | Uni-Directional |
| Typical Fall Time | 0.01 us |
| Maximum Propagation Delay Time | 60 ns |
| Maximum Power Dissipation | 200 mW |
| Lead Finish | Gold |
| Logic Gate Type | NAND Schmitt |
| Max Processing Temp | 260 |
| Output Type | Three State |
| Supplier Package | CDIP |
| Maximum Forward Voltage | 1.85 V |
| Package | 8CDIP |
| Replacement Part Number | PART-HCPL-5430 |
| Weight | Contact us |
| Country of Origin | - |
