| Part Number | HCPL-J456-300E |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 828870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler Logic-Out Pull Up DC-IN 1-CH 8-Pin PDIP SMD Tube |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCPL-J456-300E |
| Datasheet download |  HCPL-J456-300E.pdf |
| Part Number | HCPL-J456-300E |
|---|---|
| Product Dimensions | 9.8 x 6.35 x 3.56 mm |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Maximum Forward Voltage | 1.95 V |
| Lead Finish | Matte Tin |
| Operating Temperature | -40 to 100 °C |
| Mounting | Surface Mount |
| Supplier Package | PDIP SMD |
| Maximum Reverse Voltage | 3 V |
| Minimum Forward Voltage | 1.2 V |
| Maximum Power Dissipation | 145 mW |
| Output Type | Pull Up |
| Maximum Forward Current | 25 mA |
| Input Type | DC |
| Pin Count | 8 |
| MSL Level | 1 |
| Direction Type | Uni-Directional |
| Maximum Current Transfer Ratio @ Current | 90 % |
| Maximum Propagation Delay Time | 650 ns |
| Screening Level | Industrial |
| Package | 8PDIP SMD |
| Replacement Part Number | PART-HCPL-J456-300E |
| Weight | Contact us |
| Country of Origin | - |
