Please contact us for more photos of HCPL-M601-500E
| Part Number | HCPL-M601-500E |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 204870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler Logic-Out Open Collector DC-IN 1-CH 5-Pin SOIC T R |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCPL-M601-500E |
| Datasheet download |  HCPL-M601-500E.pdf |
| Part Number | HCPL-M601-500E |
|---|---|
| Minimum Forward Voltage | 1.4 V |
| Maximum Power Dissipation | 85 mW |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Maximum Forward Current | 20 mA |
| Output Type | Open Collector |
| Maximum Baud Rate | 10 MBd |
| Lead Finish | Matte Tin |
| Pin Count | 5 |
| Maximum Forward Voltage | 1.75 V |
| Maximum Reverse Voltage | 5 V |
| Mounting | Surface Mount |
| Typical Fall Time | 0.01 us |
| Input Type | DC |
| MSL Level | 1 |
| Direction Type | Uni-Directional |
| Supplier Package | SOIC |
| Maximum Propagation Delay Time | 75 ns |
| Product Dimensions | 3.6 x 4.4 x 2.5 mm |
| Package | 5SOIC |
| Replacement Part Number | PART-HCPL-M601-500E |
| Weight | Contact us |
| Country of Origin | - |
