MXA8-PW22-0000 Lumileds

Please contact us for more photos of MXA8-PW22-0000

Part Number	MXA8-PW22-0000
Manufacturer	Lumileds
Quantity in stock	779980 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color White 33lm 2200K Chip LED 2-Pin SMD T R
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	MXA8-PW22-0000
Datasheet download	MXA8-PW22-0000.pdf

Request Quotation for MXA8-PW22-0000

MXA8-PW22-0000 Specifications

Part Number	MXA8-PW22-0000
Maximum Forward Voltage per Color	3.4 V
Type	Uni-Color
Color	White
Reverse Voltage	-5 V
Screening Level	Extended Industrial
Pin Count	2
Supplier Package	SMD
Max Processing Temp	260
Rad Hard	No
Mounting	Surface Mount
Lens Shape Type	Circular
Maximum Forward Current	200 mA
Category	Chip LED
Mounting Orientation	Top Mount
Luminous Flux	33 lm
Color Temperature	2200 K
MSL Level	2
Viewing Angle	115 °
Product Dimensions	3.5 x 3.4 x 0.8
Number of LEDs	1
Lead Finish	Silver Over Nickel
Operating Temperature	-40 to 105 °C
Package	2SMD
Replacement Part Number	PART-MXA8-PW22-0000
Weight	Contact us
Country of Origin	-
