Please contact us for more photos of ICL7109CPL+
| Part Number | ICL7109CPL+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 312330 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single 30sps 12-bit Parallel 40-Pin PDIP |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ICL7109CPL+ |
| Datasheet download |  ICL7109CPL+.pdf |
| Part Number | ICL7109CPL+ |
|---|---|
| Max Processing Temp | 300 |
| Sample and Hold | No |
| Number of ADCs | 1 |
| Single-Ended Input | No |
| Differential Input | Yes |
| Operating Temperature | 0 to 70 °C |
| Supplier Package | PDIP |
| Rad Hard | No |
| Input Signal Type | Differential |
| Sampling Rate | 30 sps |
| Number of Analog Inputs | 1 |
| Voltage Supply Source | Dual |
| Lead Finish | Matte Tin |
| Input Type | Voltage |
| Pin Count | 40 |
| Product Dimensions | 52.71 x 14.61 x 4.45 mm |
| Typical Dual Supply Voltage | ±5 V |
| Digital Supply Support | No |
| Integral Nonlinearity Error | ±1 Count |
| Voltage Reference | Internal|External |
| MSL Level | 1 |
| Resolution | 12 Bit |
| Mounting | Through Hole |
| Digital Interface Type | Parallel |
| Package | 40PDIP |
| Replacement Part Number | PART-ICL7109CPL+ |
| Weight | Contact us |
| Country of Origin | - |
