Please contact us for more photos of MAX4490AUK+T
| Part Number | MAX4490AUK+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 516960 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Single GP R-R I O \u00b12.75V 5.5V 5-Pin SOT-23 T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | MAX4490AUK+T |
| Datasheet download |  MAX4490AUK+T.pdf |
| Part Number | MAX4490AUK+T |
|---|---|
| Rad Hard | No |
| Screening Level | Automotive |
| Rail to Rail | Rail to Rail Input/Output |
| Power Supply Type | Single|Dual |
| Product Dimensions | 2.9 x 1.63 x 1.1 mm |
| Minimum PSRR | 65 |
| Maximum Dual Supply Voltage | ±2.75 V |
| Minimum Single Supply Voltage | 2.7 |
| Shut Down Support | No |
| Number of Channels per Chip | 1 |
| Max Processing Temp | 260|300 |
| Maximum Operating Supply Voltage | ±2.75|5.5 V |
| Maximum Power Dissipation | 571 mW |
| Mounting | Surface Mount |
| Type | General Purpose Amplifier |
| Typical NonInverting Input Noise Current Density | 0.001@5V |
| Typical Input Noise Voltage Density | 12@5V |
| Minimum Dual Supply Voltage | ±1.35 V |
| MSL Level | 1 |
| Typical Gain Bandwidth Product | 10 |
| Lead Finish | Matte Tin |
| Pin Count | 5 |
| Minimum CMRR | 54 dB |
| Operating Temperature | -40 to 125 °C |
| Typical Voltage Gain | 110 |
| Typical Slew Rate | 10@5V V/us |
| Maximum Input Offset Voltage | 10@5V |
| Maximum Input Bias Current | 0.05@5 |
| Typical Single Supply Voltage | 3|5 V |
| Maximum Supply Current | 0.8@5V mA |
| Supplier Package | SOT-23 |
| Technology | CMOS |
| Maximum Single Supply Voltage | 5.5 V |
| Package | 5SOT-23 |
| Replacement Part Number | PART-MAX4490AUK+T |
| Weight | Contact us |
| Country of Origin | - |
