| Part Number | ATF1504ASL-25AU44 |
|---|---|
| Manufacturer | Microchip |
| Quantity in stock | 738080 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | CPLD ATF1504ASL Family 1.5K Gates 64 Macro Cells 50MHz 5V 44-Pin TQFP |
| Category | Programmable Logic IC |
| Family | CPLD |
| ROHS Compliant | Yes |
| MSL Level | ATF1504ASL-25AU44 |
| Datasheet download |  ATF1504ASL-25AU44.pdf |
| Part Number | ATF1504ASL-25AU44 |
|---|---|
| Device System Gates | 1500 |
| Product Dimensions | 10 x 10 x 1 mm |
| Number of User I/Os | 32 |
| Minimum Operating Supply Voltage | 4.5 V |
| Maximum Operating Frequency | 50 MHz |
| Maximum Propagation Delay Time | 25 ns |
| Typical Operating Supply Voltage | 5 V |
| Speed Grade | 25 |
| In System Programmability | Yes |
| Individual Output Enable Control | Yes |
| Number of Product Terms per Macro | 40 |
| Pin Count | 44 |
| Screening Level | Industrial |
| Lead Finish | Matte Tin |
| Memory Type | EEPROM |
| Supplier Package | TQFP |
| Rad Hard | No |
| Mounting | Surface Mount |
| Maximum Operating Supply Voltage | 5.5 V |
| Max Processing Temp | 260 |
| MSL Level | 3 |
| Maximum Internal Frequency | 60 MHz |
| Operating Temperature | -40 to 85 °C |
| Number of Macro Cells | 64 |
| Number of Logic Blocks/Elements | 4 |
| Re-programmability Support | Yes |
| Package | 44TQFP |
| Replacement Part Number | PART-ATF1504ASL-25AU44 |
| Weight | Contact us |
| Country of Origin | - |
