Please contact us for more photos of SST39SF010A-70-4I-NHE
| Part Number | SST39SF010A-70-4I-NHE |
|---|---|
| Manufacturer | Microchip |
| Quantity in stock | 284270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Flash Parallel 5V 1Mbit 128K x 8bit 70ns 32-Pin PLCC |
| Category | Memory IC |
| Family | Flash IC |
| ROHS Compliant | Yes |
| MSL Level | SST39SF010A-70-4I-NHE |
| Datasheet download |  SST39SF010A-70-4I-NHE.pdf |
| Part Number | SST39SF010A-70-4I-NHE |
|---|---|
| Lead Finish | Matte Tin |
| Screening Level | Industrial |
| Timing Type | Asynchronous |
| Pin Count | 32 |
| Mounting | Surface Mount |
| Support of Page Mode | No |
| Interface Type | Parallel |
| Maximum Operating Current | 25 mA |
| Architecture | Sectored |
| Maximum Programming Time | 0.02/Byte ms |
| Sector Size | 4 x 32 KB |
| Minimum Operating Supply Voltage | 4.5 V |
| Number of Words | 128 kWords |
| Address Bus Width | 17 Bit |
| ECC Support | No |
| Maximum Operating Supply Voltage | 5.5 V |
| Boot Block | No |
| Typical Operating Supply Voltage | 5 V |
| Command Compatible | Yes |
| Simultaneous Read/Write Support | Yes |
| Program Current | 35 mA |
| Product Dimensions | 14.05 x 11.51 x 2.79 mm |
| MSL Level | 3 |
| OE Access Time | 35 ns |
| Block Organization | Symmetrical |
| Erase Suspend/Resume Modes Support | No |
| Max Processing Temp | 240|300 |
| Supplier Package | PLCC |
| Number of Bits per Word | 8 Bit |
| Rad Hard | No |
| Maximum Random Access Time | 70 ns |
| Programming Voltage | 4.5 to 5.5 V |
| Operating Temperature | -40 to 85 °C |
| Density | 1 Mb |
| Maximum Erase Time | 0.1/Chip s |
| Package | 32PLCC |
| Replacement Part Number | PART-SST39SF010A-70-4I-NHE |
| Weight | Contact us |
| Country of Origin | - |
