Please contact us for more photos of TC4421CAT
| Part Number | TC4421CAT |
|---|---|
| Manufacturer | Microchip |
| Quantity in stock | 265820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MOSFET DRVR 9A 1-OUT Lo Side Inv 5-Pin(5+Tab) TO-220 Tube |
| Category | Power Management IC |
| Family | MOSFET and Power Drivers |
| ROHS Compliant | Yes |
| MSL Level | TC4421CAT |
| Datasheet download |  TC4421CAT.pdf |
| Part Number | TC4421CAT |
|---|---|
| Maximum Fall Time | 75 |
| Mounting | Through Hole |
| Lead Finish | Matte Tin |
| Supplier Package | TO-220 |
| Pin Count | 5 |
| Output Resistance | 0.9|1.4 Ohm |
| Maximum Supply Current | 1.5 |
| Maximum Operating Supply Voltage | 18 V |
| Minimum Operating Supply Voltage | 4.5 V |
| Screening Level | Commercial |
| Number of Outputs | 1 |
| Driver Configuration | Inverting |
| Input Logic Compatibility | CMOS|TTL |
| Maximum Power Dissipation | 1600 mW |
| Maximum Rise Time | 75 |
| Maximum Propagation Delay Time | 60 |
| Driver Type | Low Side |
| Product Dimensions | 10.67 x 4.83 x 9.02 mm |
| Number of Drivers | 1 |
| Operating Temperature | 0 to 70 °C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Peak Output Current | 9 A |
| Package | 5TO-220 |
| Replacement Part Number | PART-TC4421CAT |
| Weight | Contact us |
| Country of Origin | - |
