Please contact us for more photos of M25P80-VMW6TG
| Part Number | M25P80-VMW6TG |
|---|---|
| Manufacturer | Micron |
| Quantity in stock | 333250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | NOR Flash Serial-SPI 3.3V 8Mbit 1M x 8bit 8ns 8-Pin SO W T R |
| Category | Memory IC |
| Family | Flash IC |
| ROHS Compliant | Yes |
| MSL Level | M25P80-VMW6TG |
| Datasheet download |  M25P80-VMW6TG.pdf |
| Part Number | M25P80-VMW6TG |
|---|---|
| Sector Size | 64 x 16 KB |
| Screening Level | Industrial |
| Programming Voltage | 2.7 to 3.6 V |
| Maximum Operating Current | 8 mA |
| Program Current | 15 mA |
| Address Bus Width | 1 Bit |
| Simultaneous Read/Write Support | No |
| Cell Type | NOR |
| Architecture | Sectored |
| Block Organization | Symmetrical |
| Support of Page Mode | No |
| ECC Support | No |
| Command Compatible | Yes |
| Number of Bits per Word | 8 Bit |
| Boot Block | No |
| Erase Suspend/Resume Modes Support | No |
| Number of Words | 1 MWords |
| Maximum Random Access Time | 8 ns |
| Typical Operating Supply Voltage | 3.3 V |
| Timing Type | Synchronous |
| Maximum Programming Time | 5/Page ms |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Maximum Erase Time | 20/Chip s |
| Product Dimensions | 6.05 x 6.22 x 2 mm |
| Supplier Package | SO W |
| Page Size | 256 byte |
| Interface Type | Serial (SPI) |
| Density | 8 Mb |
| Minimum Operating Supply Voltage | 2.7 V |
| Maximum Operating Supply Voltage | 3.6 V |
| Mounting | Surface Mount |
| Pin Count | 8 |
| Package | 8SO W |
| Replacement Part Number | PART-M25P80-VMW6TG |
| Weight | Contact us |
| Country of Origin | - |
