Please contact us for more photos of N25Q128A13ESE40G
| Part Number | N25Q128A13ESE40G |
|---|---|
| Manufacturer | Micron |
| Quantity in stock | 601460 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | NOR Flash Serial-SPI 3V 3.3V 128Mbit 128M 64M 32M x 1bit 2bit 4bit 7ns 8-Pin SO W Tube |
| Category | Memory IC |
| Family | Flash IC |
| ROHS Compliant | Yes |
| MSL Level | N25Q128A13ESE40G |
| Datasheet download |  N25Q128A13ESE40G.pdf |
| Part Number | N25Q128A13ESE40G |
|---|---|
| Location Of Boot Block | Bottom|Top |
| Supplier Package | SO W |
| Maximum Operating Current | 20 mA |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Product Dimensions | 6.05 x 6.22 x 2 mm |
| Architecture | Sectored |
| Cell Type | NOR |
| Sector Size | 4 x 4096 KB |
| Density | 128 Mb |
| Erase Suspend/Resume Modes Support | Yes |
| Address Bus Width | 1 Bit |
| Block Organization | Symmetrical |
| Maximum Random Access Time | 7 ns |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Programming Voltage | 2.7 to 3.6|8.5 to 9.5 V |
| Number of Bits per Word | 1/2/4 Bit |
| Simultaneous Read/Write Support | No |
| Page Size | 256 byte |
| Boot Block | Yes |
| Interface Type | Serial (SPI) |
| Timing Type | Synchronous |
| Typical Operating Supply Voltage | 3|3.3 V |
| Program Current | 20 mA |
| Pin Count | 8 |
| ECC Support | No |
| Maximum Erase Time | 250/Chip s |
| Support of Common Flash Interface | No |
| Maximum Programming Time | 5/Page ms |
| Command Compatible | Yes |
| Maximum Operating Supply Voltage | 3.6 V |
| Support of Page Mode | No |
| Screening Level | Industrial |
| Minimum Operating Supply Voltage | 2.7 V |
| Number of Words | 128/64/32 MWords |
| Package | 8SO W |
| Replacement Part Number | PART-N25Q128A13ESE40G |
| Weight | Contact us |
| Country of Origin | - |
