Please contact us for more photos of 0366380003
| Part Number | 0366380003 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 205820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn CMC HDR 48 POS Solder RA Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Rectangular |
| ROHS Compliant | Yes |
| MSL Level | 0366380003 |
| Datasheet download |  0366380003.pdf |
| Part Number | 0366380003 |
|---|---|
| Body Orientation | Right Angle |
| Contact Material | Brass |
| Gender | RCP |
| Housing Material | Polybutylene Terephthalate |
| Termination Method | Solder |
| Lead Finish | Tin |
| Product Dimensions | 58.5 x 56.5 x 30.9 mm |
| Contact Plating | Tin Over Nickel |
| Mounting | Through Hole |
| Operating Temperature | -40 to 100 °C |
| Product Depth | 56.5 mm |
| Product Height | 30.9 mm |
| Product Length | 58.5 mm |
| Replacement Part Number | PART-0366380003 |
| Weight | Contact us |
| Country of Origin | - |
