Please contact us for more photos of 0503509001
| Part Number | 0503509001 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 604530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Contact SKT Crimp ST Cable Mount Reel |
| Category | Connectors |
| Family | Connector Contacts |
| ROHS Compliant | Yes |
| MSL Level | 0503509001 |
| Datasheet download |  0503509001.pdf |
| Part Number | 0503509001 |
|---|---|
| Shielded | No |
| Body Orientation | Straight |
| Termination Method | Crimp |
| Lead Finish | Tin |
| Contact Plating | Tin |
| Contact Material | Brass |
| Wire Size | 16 to 18 AWG |
| Contact Type | Power |
| Product Dimensions | 10.4 x 3.6 x 4.6 mm |
| Mounting | Cable Mount |
| Gender | SKT |
| Connector Type | Connector Headers and PCB Receptacles |
| Product Depth | 3.6 mm |
| Product Height | 4.6 mm |
| Product Length | 10.4 mm |
| Replacement Part Number | PART-0503509001 |
| Weight | Contact us |
| Country of Origin | - |
