Please contact us for more photos of 0526100871
| Part Number | 0526100871 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 307710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn FFC FPC Connector SKT 8 POS 1mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector FFC-FPC |
| ROHS Compliant | Yes |
| MSL Level | 0526100871 |
| Datasheet download |  0526100871.pdf |
| Part Number | 0526100871 |
|---|---|
| Housing Color | Natural |
| Contact Gender | SKT |
| Lead Finish | Tin/Bismuth |
| Product Dimensions | 14.6 x 3.6 x 5.75 mm |
| Contact Plating | Tin Over Nickel |
| Contact Material | Phosphor Bronze |
| Pitch | 1 mm |
| Operating Temperature | -40 to 85 °C |
| Housing Material | Nylon 4/6 |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Termination Method | Solder |
| Product Depth | 3.6 mm |
| Product Height | 5.75 mm |
| Product Length | 14.6 mm |
| Replacement Part Number | PART-0526100871 |
| Weight | Contact us |
| Country of Origin | - |
