Please contact us for more photos of 437438101
| Part Number | 437438101 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 262830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn RJ-45 RCP 8 POS 1.27mm Solder RA SMD 8 Terminal 1 Port Embossed T R Cat 3 |
| Category | Connectors |
| Family | Connector Telephone and Telecom |
| ROHS Compliant | Yes |
| MSL Level | 437438101 |
| Datasheet download |  437438101.pdf |
| Part Number | 437438101 |
|---|---|
| Operating Temperature | -40 to 80 °C |
| Pitch | 1.27 mm |
| Contact Plating | Gold Over Nickel |
| Housing Material | Polyamide |
| Max Processing Temp | 235 |
| Contact Material | Phosphor Bronze |
| Termination Method | Solder |
| Product Dimensions | 20.24 x 16.89 x 11.74 mm |
| Lead Finish | Tin |
| Gender | RCP |
| Body Orientation | Right Angle |
| Mounting | Surface Mount |
| Product Depth | 16.89 mm |
| Product Height | 11.74 mm |
| Product Length | 20.24 mm |
| Replacement Part Number | PART-437438101 |
| Weight | Contact us |
| Country of Origin | - |
