Please contact us for more photos of 449146803
| Part Number | 449146803 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 659300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 18 POS 3mm Solder ST Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 449146803 |
| Datasheet download |  449146803.pdf |
| Part Number | 449146803 |
|---|---|
| Mounting | Through Hole |
| Housing Material | Thermoplastic |
| Termination Method | Solder |
| Lead Finish | Tin |
| Contact Plating | Gold |
| Pitch | 3 mm |
| Housing Color | Black |
| Body Orientation | Straight |
| Operating Temperature | -40 to 105 °C |
| Gender | HDR |
| Contact Material | High Performance Alloy |
| Replacement Part Number | PART-449146803 |
| Weight | Contact us |
| Country of Origin | - |
