Please contact us for more photos of 5023801200
| Part Number | 5023801200 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 337570 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Housing PL 12 POS 1.25mm Crimp ST Cable Mount Bag |
| Category | Connectors |
| Family | Connector Discrete Wire Housing |
| ROHS Compliant | Yes |
| MSL Level | 5023801200 |
| Datasheet download |  5023801200.pdf |
| Part Number | 5023801200 |
|---|---|
| Gender | PL |
| Wire Size | 26 to 28 AWG |
| Operating Temperature | -25 to 85 °C |
| Mounting | Cable Mount |
| Rad Hard | No |
| Pitch | 1.25 mm |
| Housing Color | White |
| Housing Material | Polybutylene Terephthalate |
| Body Orientation | Straight |
| Product Dimensions | 16.25 x 7.05 x 5.45 mm |
| Product Depth | 7.05 mm |
| Product Height | 5.45 mm |
| Product Length | 16.25 mm |
| Replacement Part Number | PART-5023801200 |
| Weight | Contact us |
| Country of Origin | - |
