Please contact us for more photos of 5034801600
| Part Number | 5034801600 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 160000 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn FFC FPC Connector RCP 16 POS 0.5mm Solder RA SMD Embossed T R |
| Category | Connectors |
| Family | Connector FFC-FPC |
| ROHS Compliant | Yes |
| MSL Level | 5034801600 |
| Datasheet download |  5034801600.pdf |
| Part Number | 5034801600 |
|---|---|
| Housing Color | Natural |
| Housing Material | Liquid Crystal Polymer |
| Operating Temperature | -40 to 85 °C |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Over Nickel |
| Pitch | 0.5 mm |
| Body Orientation | Right Angle |
| Rad Hard | No |
| Mounting | Surface Mount |
| Product Dimensions | 9.7 x 4 x 1 mm |
| Termination Method | Solder |
| Contact Gender | RCP |
| Product Depth | 4 mm |
| Product Height | 1 mm |
| Product Length | 9.7 mm |
| Replacement Part Number | PART-5034801600 |
| Weight | Contact us |
| Country of Origin | - |
